Configure up to 32 behaviour statements, expandable up to a maximum of 12 inputs and 12 outputs. Configuration via USB, using SmartSetup software (free). No ADVANCED logic control. Lite 4G functions on AirDrive platform (Status viewing only).
Product Highlights
- Easy to set up with point-and-click SmartSetup computer software. Up to 32 statements
- Base unit with 2x opto-isolated digital inputs (expandable up to 12 inputs)
- Base unit with 2x 8amp relay outputs (expandable up to 12 outputs)
- 1 Analog input
- 10 – 24vDC power input
- 1 Battery backup input & trickle charge function
- 2 Temperature inputs (Must use GT008)
- RS485 – Modbus RTU
- SMS, Voice call and basic GPRS capability
Technical Specifications
| Digital Inputs: | Opto-isolated. Inputs draw 10-30mA, depending on the voltage. Can accept DC signals of any type, including:
|
| Digital Outputs: | SPDT Relays |
| Rating: | 8Amp DC (10-48v) ) OR 4Amp AC (110-400v) (non inductive loads) |
| Current Consumption: | 60mA at Idle (no inputs or outputs active) |
| Power Supply: | 10-24V DC via DC Jack or Screw Terminal |
| Operating Temperature: | -10 to +60Ì C |
| Storage Temperature: | -20 to +85Ì C |
| Dimensions: | 148 x 86 x 28mm |
NB: If the onboard Analog input is going to be utilized. Please purchase an External power supply as well
